ELP 4K Manual Focus Zoom Webcam IMX317 Color FHD 2160P 1080P 30fps Audio Video Conference Camera USB2.0 Plug Play For Ra

ELP 4K Manual Focus Zoom Webcam IMX317 Color FHD 2160P 1080P 30fps Audio Video Conference Camera USB2.0 Plug Play For Raspberry Pi Android Development Board

ELP 4K Manual Focus Zoom Webcam IMX317 Color FHD 2160P 1080P 30fps Audio Video Conference Camera USB2.0 Plug Play For Raspberry Pi Android Development Board

4K/2160P USB Webcam,Ultra HD Sony IMX317 Image Sensor with Manual Focus Optical Zoom Lens Varifocal Focus Adjustable

SPECIFICATION :

Sensor :SONY IMX317 (1/2.5”)

Max Resolution :3840(H) x2160 (V)

Picture format :MJPEG /YUY2 (YUYV)

IR Filter: 650±10nm

Operating System Win XP/Vista/Win7/Win8 / Linux with UVC(above linux-2.6.26)



MAC-OS X 10.4.8 or later/Android 4.0 or above with UVC



Features

* 4K Camera , High resolution Max 3840(H) *2160 (V) , suitable for document capture
*Advanced IMX317 (1/2.5" ) Color CMOS image sensor , more efficiency .
* Optical Zoom webcam CS Mount, 5-50mm or 2.8-12mm varifocal lens optional , support manual focus ,aperature ,sharpness .
*USB Audio Camera ,inbuilt dual microphone .
*High speed 30fps at 3840x2160P ,30FPS@1920X1080 .
* Camera with UVC ,free driver ,compatible with most OS:  Win XP/Vista/Win7/Win8 / Linux with UVC(above linux-2.6.26)
MAC-OS X 10.4.8 or later/Android 4.0 or above with UVC

Datasheet



Model
ELP-USB4KHDR01-MFV(5-50)
Sensor
SONY IMX317 (1/2.5”)
Max Resolution
3840(H) *2160 (V)
Sensitivity
1000mV/Lux-sec
Image area
6100^mx4524^m
Picture format
MJPEG /YUY2 (YUYV)
Resolution FPS
3840x2160@ 30fps MJPEG/ 2592x1944@ 30fps MJPEG
2048x1536@ 30fps MJPEG /1600x1200@ 30fps MJPEG
1920x1080@ 30fps MJPEG/ 1280x1024@30fps MJPEG
1280x960@30fps MJPEG/1280x720@ 30fps MJPEG
1024 x 768@ 30fps MJPEG/ 800 x 600@ 30fps MJPEG
640x480@ 30fps MJPEG/ 320x240@ 30fps MJPEG

3840x2160@ 1fps YUY2 / 2592x1944@ 1fps YUY2
2048x1536@ 3fps YUY2 /1600x1200@ 3fps YUY2
1920x1080@ 3fps YUY2/ 1280x1024@3fps YUY2
1280x960@5fps YUY2/1280x720@ 5fps YUY2
1024 x 768@ 5fps YUY2/ 800 x 600@ 20fps YUY2
640x480@ 30fps YUY2 / 320x240@ 30fps YUY2
Center Definition
1000LW/PH (Center)
S/N (Signal Noise Ratio)
26dB
Sensitivity
0.65V/lux-sec@550nm
Low illumination
0.2lux
Shutter
Electronic rolling shutter / Frame exposure
Interface
USB2.0 High Speed
AEC
Support
AEB
Support
AGC
Support
Adjustable Parameters
Brightness, Contrast, Saturation, Hue, Sharpness, Gama, White Balance,
Backlight Contrast, Exposure
Lens
Size: 1/2.3”, 5-50mm varifocal lens
Relative Illumination (Sensor): 70%
IR Filter: 650±10nm
Power Supply Connector
USB BUS POWER 4P-2.0mm socket
Power
DC5V
Current
200mA
Size
38mm x 38mm
Storage Temperature
-20°C to 70°C
Working Temperature
0°C to 60°C
USB Cable
1M(2M/3M/5M Optional)
Operating System
Win XP/Vista/Win7/Win8 / Linux with UVC (above linux-2.6.26)
MAC-OS X 10.4.8 or later/Android 4.0 or above with UVC






4K USB Webam,Ultra HD 5-50mm 10x optical zoom webcam -Focus Aperture Distance Adjustable

4K USB Camera,Ultra HD 2160P@30FPS USB Webcam with Sony IMX317 Sensor work effieciency

4K USB Webam Built In Microphone dual audio in .

Resolution FPS:

3840x2160@ 30fps MJPEG / 2592x1944@ 30fps MJPEG /2048x1536@ 30fps MJPEG /1600x1200@ 30fps MJPEG/1920x1080@ 30fps MJPEG/ 1280x1024@30fps MJPEG/1280x960@30fps MJPEG/1280x720@ 30fps MJPEG/1024 x 768@ 30fps MJPEG/ 800 x 600@ 30fps MJPEG

640x480@ 30fps MJPEG / 320x240@ 30fps MJPEG/3840x2160@ 1fps YUY2 / 2592x1944@ 1fps YUY2/2048x1536@ 3fps YUY2 /

1600x1200@ 3fps YUY2/1920x1080@ 3fps YUY2/ 1280x1024@3fps YUY2/1280x960@5fps YUY2/1280x720@ 5fps YUY2

1024 x 768@ 5fps YUY2/ 800 x 600@ 20fps YUY2/640x480@ 30fps YUY2 / 320x240@ 30fps YUY2

4K USB Camera,2160P@30fps Focus Adjustable USB Camera Lens with Sony IMX317 Sensor, USB2.0 PlugPlay for Mac Raspberry Linux Windows

WARM TIPS :

The maximum resolution of some software or screens only supports 1080P or 720P, In order to enjoy Ultra clear 4K 8 megapixels image or video of this webcam, Please make sure your software and screen support 4K. 2.8-12mm and 5-50mm varifocal lens, there may be a little dark corner on the edge of the screen image .

4K USB Webcam, Ultra HD 5-50mm Varifocal Lens USB Camera with Sony IMX317 Image Sensor Mini USB Webcam, UVC Zoom Live Steaming Video Conference Webcam for Mac/Window/Linux/Raspberry Pi

Free Driver Plug and Play USB Camera

Easy to set up:

Our usb webcam is very easy to set up, USB 2.0 connector more effective in data transmission great save time for you . Easy to use, available USB port, compatible with most social media platform.

You can easily put this USB camera on desktop, or mount on a tripod for wider use range, and enjoy different view with the zoom lens.

4K Ultra HD High Definiton USB Camera

4K usb camera with max resolution:

3840x2160@30fpsMJPEG, support2592x1944@ 30fps MJPEG 2048x1536@ 30fps MJPEG /1600x1200@ 30fps MJPEG. USB 2.0 webcam, fast transmission, UHD lens and high quality makes your recorded video clear, vivid and colorful.

Wide Application

4k/2160P USB camera for all kinds of machine vision. Wide application for:


  1. VR camera

  2. 3D scanner

  3. Medical machine

  4. Smart box TV BOX

  5. Advisement player

  6. Electronic microscope

  7. Automatic vending machine

  8. Automated image acquisition system
